The Nebulas of Auriga Mosaic

Auriga Mosaic

The Auriga Constellation contains dozens of nebulas and other objects well-known to astronomers, both amateur and professional. But everyone else is largely unaware of them. This field captures a giant emission region that encompasses such objects as the Flaming Star Nebula, the Tadpoles, the Spider and the Fly, the Gripping Hand, and the Great Pumpkin. Tucked into its folds the open star cluster Messier 38, the Starfish Cluster, also makes an appearance.



Shooting this mosaic was a monumental commitment of time and effort. It required almost every dark-sky minute for the TOA130 from October 2023 through March 2024. Then it required several weeks of time to stitch together and process into the image above. I intentionally framed it so that several of the individual tiles could be published as separate images of some of the fascinating images in the object. Those will appear on this site at some point. The image cuts a wide swath through the Auriga Constellation. More than 100 full moons could fit inside the field.



I could write a three-volume treatise about what is going on in this image. Fortunately, Jeff Kanipe and Dennis Webb have essentially already done that. So instead, I’ll provide a crop and short description of each of the major formations in the frame, with great deference to Messrs. Kanipe and Webb and their amazing series of books, Annals of the Deep Sky.



IC 405, Sh2-229, and vdB 34 – The Flaming Star Nebula
IC 405, Sh2-229, and vdB 34 – The Flaming Star Nebula

IC 405, the Flaming Star Nebula, contains both an emission region catalogued as Sh2-229, and a reflection nebula catalogued as vdB 34. It lies 1,500 light years away and spans 2.5 light years. The giant central star, AE Aurigae, is a runaway star—a star moving so fast it will eventually leave the galaxy. But while it’s passing through, its extreme outflow of radiation is ionizing the gasses in its path, some of which are also reflecting its light.



IC 410, NGC 1893, and Sh2-236 – The Tadpoles
IC 410, NGC 1893, and Sh2-236 – The Tadpoles

NGC 1893, the Tadpoles Nebula, refers to the star cluster illuminating the emission nebula catalogues as IC 410 and Sh2-236. Inside that nebulous area, you can see two streamers of colder, darker gas that give the nebula its colloquial name. Catalogued as Sim 129 and Sim 130, each tadpole is roughly 10 light years long and they likely contain nascent stars. Though it looks smaller than the Flaming Star, it’s 40 times its size at 100 light years across. It merely looks smaller because it’s so much farther away at a distance of 12,000 light years.



IC 417 & Sh2-234 – The Spider and NGC 1931 & Sh2-237 – The Fly



Known as the Fly Nebula, NGC 1931 is another star cluster buried in a small nebulous formation, Sh2-237. It’s companion, and sworn enemy the Spider Nebula, IC 417 and Sh2-234, lies close by, ready to entangle it. The Fly is about 7,000 light years from us while the Spider has some ground to cover at 10,000 light years away.



M38 – The Starfish Cluster
M38 – The Starfish Cluster

Roughly 4,200 light years away, the Starfish Cluster, Messier 38 (M3) is one of three open star clusters Messier catalogued in Auriga—the other two being M36 and M37.


Sh2-230 – The Gripping Hand
Sh2-230 – The Gripping Hand

The emission region Sh2-230 is not a particularly popular target, and there is a dearth of information about it on the interwebs. But it has long fascinated me, appearing as a large claw reaching out to grab its companions in Auriga. So I gave it the personal name The Gripping Hand—an homage to the sequel to The Mote in God’s Eye by Larry Niven and Jerry Pournelle. Distance measurements are all over the map, but many seem to agree that it is between 7,000 and 10,000 light years away.



Sh2-232 – The Great Pumpkin with Sh2-231, 233, and 235 (clockwise from L)



Sometimes referred to as The Great Pumpkin Nebula, Sh2-232 is part of a larger complex of HII regions associated with the G174+2.5 molecular cloud along with Sh2-231, 233, and 235. The distance to Sh2-235 has been measured at around 6,000 light years.

LDN 1251-Rotten_Fish-FSQ-DSW-2024-11-FB.jpg
Constellations
Auriga
Auriga
Hemisphere:
Northern
Sh2-157-Lobster Claw-TOA-DSW-SHO-2024-10-FB.jpg
Object Types
Emission Nebulas
Emission Nebula
Open Star Clusters
Open Star Cluster
NGC 7822-Question Mark-RC71-Home-2024-10-II-FB.jpg
Telescope
Takahashi TOA130
Takahashi TOA130
Mr Magoo-TOA-DSW-2024-10-APOD.jpg
Finder Chart
Auriga Mosaic

Click to expand

Sh2-82-CDK-DSW-2024-10-8K Crop.jpg
Image Capture

Total integration: 182h 1m


Integration per filter:

- R: 2h 22m (142 × 60")

- G: 2h 22m (142 × 60")

- B: 2h 22m (142 × 60")

- Hα: 61h 20m (736 × 300")

- SII: 57h 35m (691 × 300")

- OIII: 56h (672 × 300")


Coordinates: 5h 27m 34s · +35° 5′ 45″
